Add SAM data to the Node Details view

To view SAM data, including application and component monitor information, you may need to edit the Node Details - Summary view to include relevant views and widgets (formerly called "resources").

You may need to log in with an administrator account to perform this action.

  1. In the Orion Web Console, click Settings > All Settings > Manage Views.
  2. Select the Node Details - Summary and click Edit.
  3. On the Customize Node Details page, click [+] in the column where you want to add SAM widgets.

    To list SAM specific widgets on the Add Resource page, select the Group By Classic Category and select SAM Application Summary Resources. These options include widgets such as the All Applications Tree, AppStack Environment, and AppInsight widgets.

  4. Click Add Selected Resources to save all selections to the column.

  5. Click Done to update the view.

To check the view, navigate to a node you edited to see the latest layout. Edit the view again to modify ifs necessary.

To learn more about customizing views and widgets, see the Orion Platform Administrator Guide.
